PATTERNS
Experience our range of classic to contemporary design patterns cut out of Zintra™. Whether it is the Zintra™ pattern layer only or the Zintra™ pattern on a matching or contrasting solid Zintra™ Panel as the backer, it will create a unique look for walls, dividers, or ceilings. In just the one product you will find style, texture, contrast and depth with the added benefit of sound absorption and sound refraction to create a harmonious environment. The two layers of Zintra™ Acoustic Patterns also increases the NRC value.
FEATURES
  • NRC = 0.45 - 0.95 depending on design and installation method
  • To use as pattern layer only or the pattern layer with Zintra™ Acoustic 1/2" backing
  • Easy installation using Z-clips, adhesive or other mechanical mounting methods
  • Tone-on-tone or two tone color combinations
  • Ability to easily customize design for specific project requirements
  • Apply directly to walls or ceilings or use as room dividers
  • SPECIFICATIONS
    CONTENT
    100% Polyester
    ACOUSTIC RATING
  • 0.45-0.95 NRC
  • PANEL SIZE
  • 2' x 2' x 1" panels / 610mm x 610mm x 24mm
  • 2' x 4' x 1" panels / 610mm x 1220mm x 24mm
  • 4' x 9' x 1" panels / 1220mm x 2745mm x 24mm
  • Pattern Only is 1/2" (12 mm) thick
  • SURFACE FINISH
    Matte
    WEIGHT
    0.5 - 1 lb / ft2 / 2.4 - 4.8 kg / m2 depending on design
    COLOURS
    16 standard colors.
    APPLICATION
    Indoor areas only.
    FABRICATION
    Utility knife or CNC with oscillating knife.
    INSTALLATION
  • Adhere to substrate with adhesive.
  • Attach with screws, nails, stand-offs or with aluminum trim or millwork.
  • FIRE RATING
    In accordance with ASTM-E84, Zintra™ Acoustic 1/2" Panels achieve a Class A Flame Spread - passes CAN ULC S102-10.
    CARE INSTRUCTIONS
  • Vacuum to remove dust.
  • Remove spills immediately using a clean damp cloth or with soap and water.
  • Carpet and fabric cleaners can be used - always test an inconspicuous area first.
  • Stain repellant coating available for additional protection.
  • HOW TO CREATE YOUR OWN PATTERN IN 3 EASY STEPS
    1
    Select your
    pattern & size
    2
    Choose your
    pattern colour
    3
    Choose your
    background colour
    PATTERNS
    Abhaya
    Asiatic
    Astra
    Bengal
    Bharata
    Bhushan
    Deepak
    Devraj
    Elephanta
    Gadiva
    Haimati
    Indus
    Kali
    Kerala
    Krishnan
    Malini
    Mandava
    Monsoon
    Nadu
    Padmesh
    Raja
    Sakra
    Sankaran
    Sanskrit
    Sutra
    Telugu
    Vedic
    Wamika
    Prose
    Punto
    Siptical
    Hex
    COLOURS
    Tar
    Sky
    To order a sample please select a desired colour.
    To place an order for Zintra Acoustic Solutions please call Customer Service: 1-800-268-1300
